Integral Earth Leakage Relay

Key Features

• Monitors, True RMS Earth Leakage Current.
• Integral toroid-35mm Ø
• Earth Leakage Relay with Inbuilt CBCT of three variant available:30mA, 100mA, 300mA
• “Test” and “Reset” push buttons.
• SPDT Output Relay with Energized to trip.
• Protected against the nuisance tripping.
• Green LED indicates presence of power supply.
• Red LED flashing indicates when fault current is >50% of ▲ n & fault current is >75% LED ON as relay has tripped.
• Base or DIN rail Mounting.
• Easy to install and compact size.
